防止空氣凈化工程微粒子污染的四項基本原則
- 發布人：
- 發布日期：2017-04-13 17:47:35
空氣凈化工程的浮游微粒子濃度，使用高性能的過濾器即可容易達到零水平，實際的生產現場由于作業者、機器、周邊機械的發塵及基板運送時所接觸的零件材料的發塵等，在制造品周邊揚起了少許的微粒子，因而造成了元件清潔面的粒子污染。
Air purification engineering of planktonic particles concentration, using high performance filter can be easily reached the zero level, actual production site due to the operator and machine, peripheral machinery of dust and substrate transport the contact parts of the material dust etc., in manufacturing goods surrounding raised a little particles, resulting in the components clean surface particle pollution.
空氣凈化工程 http://www.jnjkjh.com/ 該如何防止微粒子污染呢？應遵守下列四項基本原則：
How to prevent the pollution of particulate? The following four basic principles should be followed:
1） 不攜入
1) not to bring in
在無塵室內不攜入微粒子的方法有：
In the clean room and do not carry particles with details:
作業員進入無塵室前，機臺、零件攜入前應進行清潔處理；
Before entering the clean room, the operator should be cleaned with the machine and the parts before entering the clean room;
進入無塵室者在更衣室要穿著不發塵、不產生靜電的具特殊導電性纖維材質的無塵服、帽、鞋、手套、口罩等。
Into the clean room in the dressing room to wear no hair, no static electricity with a special conductive fiber material of clean clothes, caps, shoes, gloves, masks, etc..
通過風淋室時利用高速干凈空氣除去附在衣服表面的粒子后，才能進入無塵室。
Through the air shower room, the use of high speed clean air to remove the particles attached to the surface of the clothes, in order to enter the clean room.
機器及材料帶進無塵室前，應盡可能在密封狀態下帶進無塵室前室保養后用超純水擦拭，經風淋室吹淋后才進入無塵室。
In front of the machine and material into the clean room, should as far as possible in a sealed condition in the maintenance of the clean room antechamber with ultrapure water wipe, after the air shower room shower before entering the clean room.
無塵室中須全程穿戴密閉式安全帽及佩戴附有filter的排氣用小型fan于腰間。
With a small fan in the waist to wear full exhaust closed type safety cap and worn with a filter of the clean room.
2） 不發生
2) no
在控制最大污染源--人在無塵室內的微粒子發塵量的同時，也應控制第二大污染源—制造機臺的發塵量。因物品在移動時，所產生的摩擦及接觸剝離會造成發塵，而物品在移動時也會有微粒子的發生。故為了控制空氣凈化工程發塵量達到最小限度應采取以下對策：
In control of the largest pollution source - the dust in the dust of the dust particles in the dust chamber, it should control the second pollution sources - making machine dust. Because of the movement of goods, the resulting friction and contact stripping can cause hair dust, while the goods will have the occurrence of particles in the movement. Therefore, in order to control the air purification project dust quantity to reach the minimum should take the following measures:
減少接觸剝離發塵的動作形態；
Reduction of the action form of contact stripping hair;
采用磨耗發塵小的材質；
The material used in the wear hair dust;
采用發塵小的潤滑油；
Use small lubricating oil;
機臺應用空壓浮上的非接觸化工作原理。
Principle of non - contact operation of air pressure floating on the machine.
3） 不儲備
3) No Reserve
若能徹底實施“不攜入”技術，空氣凈化工程的潔凈度就可以維持。但現實中人和物品的頻繁出入及制造機臺的掣動，在廣大的無塵室內要有完全潔凈度是不可能的。因此“不儲備”技術快速地在過濾器中應用以除去已發生的微粒子變得非常重要。通常已發生的微粒子會依據重力及靜電吸附力而停留在周邊的物體表面。突發性的振動及不穩定的氣流會使這些累積微粒在空氣中再度揚起，增加了重大微粒子污染的危險性。
If the implementation of the "no" technology, air purification project can be maintained clean. But reality of people and goods was frequent and manufacturing machine button, in the majority of the clean room to have completely cleanliness is not possible. Therefore, the "non - reserve" technique is applied to the filter to remove the particles that have been taken place very important. Usually the particles that have been taken will remain in the vicinity of the object surface by gravity and electrostatic forces. The sudden vibration and unstable air flow can cause the accumulation of particles to be raised again in the air, and increase the risk of contamination of the major particles.
在最高等級的無塵室中從天花板到地面，完全除去微粒子的空氣須在0.3-0.4m/s的速度作垂直向下流動。這是在約10秒內將室內空氣和完全過濾空氣完全交換所計算出來的數值。同時，空氣的流向也必須要有精確的控制才行。特別要保證氣流的流通路徑暢通無阻，因為在流通路徑中有障礙物的話，容易產生空氣空氣渦流而形成空氣的滯留區域，使得附近已發生的微粒子無法快速排除而長時間漂流在無塵室內，而一部分會附著在周邊機器設備的表面而引起污染。
From the ceiling to the ground in the highest level of the clean room, the air to completely remove the particles from the ceiling is required to be vertically downward at the speed of 0.3-0.4m/s. This is calculated by the full exchange of the indoor air and the fully filtered air in about 10 seconds. At the same time, the flow of air must have a precise control. Especially to ensure the smooth flow of the flow path, because there are obstacles in the flow path, easy to produce air vortex and the formation of air stagnation zones, making near has occurred particles cannot quickly ruled out long time drifting in the clean room, and a branch of attachment in the peripheral equipment of surface caused by pollution.
控制氣流可防止微粒子累積，但對于帶電表面的微粒累積就無法防止。為了防止由靜電吸附而引起的微粒附著，通常在無塵室內會使用帶電程度在數十伏以下的導電性材料。而對于制造品本身的帶電，則采用帶電程度很少的搬送形態及接觸部品材料，并藉由除電裝置進行除電。
Control air flow can prevent the accumulation of particles, but can not prevent the accumulation of particles on the charged surface. In order to prevent the particles attached to the particles by electrostatic adsorption, it is usually used in the clean room to use the electrical conductivity of the electricity in the following several decades. And for the manufacture of the product itself, the use of electricity to carry out the form and the contact of the material, and by the electric device.
4） 排除/除去
4) exclusion / removal
在無法避免大量微粒子發生的機臺中，為了不讓無塵室內產生微粒子，因此直接做對外排氣的動作，即所謂的局部排氣。針對排氣的對策如下：由于導入同量的外氣是必要的，但會伴隨大量的能源消耗。所以無法說是絕對理想的對策。因此盡可能地在壓縮排氣量的同時，不僅僅是向無塵室外排氣，而應采用將除去粒子后的空氣再回流到無塵室內之對策。
In order to prevent the occurrence of a large number of particles in the machine, in order not to produce particles, so directly do the external exhaust, the so-called local exhaust. The countermeasures are as follows: the introduction of exhaust gas amount is necessary, but will be accompanied by a large amount of energy consumption. So can not say that is absolutely ideal strategy. Therefore, as far as possible in the compression of the exhaust volume, not only to clean out the air, and should be used to remove the air and then return to the dust chamber of the countermeasures.
